Infix Prefix Postfix Conversion (Stack)

Postfix Prefix Infix

Why we use Postfix Prefix & Infix?

Postfix, Prefix expressions are faster to execute for the compiler than simple infix expression, as the compiler doesnt have to care about operator predence in case of postfix and prefix.

Introduction

  • Operation : Any Expression of algebraic format (Example : A + B)
  • Operands : A and B or 5 & 6 are operands
  • Operators : +. -, %,*,/ etc are operators

Infix Notation

Infix is the day to day notation that we use of format A + B type. The general form can be classified as (a op b) where a and b are operands(variables) and op is Operator.

  • Example 1 : A + B
  • Example 2 : A * B + C / D

Postfix Notation

Postfix is notation that compiler uses/converts to while reading left to right and is of format AB+ type. The general form can be classified as (ab op) where a and b are operands(variables) and op is Operator.

  • Example 1 : AB+
  • Example 2 : AB*CD/+

Prefix Notation

Prefix is notation that compiler uses/converts to while reading right to left (some compilers can also read prefix left to right) and is of format +AB type. The general form can be classified as (op ab) where a and b are operands(variables) and op is Operator.

  • Example 1 : +AB
  • Example 2 : +*AB/CD
Postfix Prefix and Infix

Why Postfix/Prefix Expressions are faster than Infix?

For Infix Expression which is format A+B*C, if the compiler is reading left to right then it can’t evaluate A+B first until it has read whole expression and knows expression is actually A + (B*C) i.e. B * C needs to be implemented first

Postfix for above infix is ABC*+. Now, as soon as compiler sees two operands followed by operator it can implement it without caring for precedence.

  • Assume ABC*+
  • ABC*+ (BC* is implemented as B*C and result is put back)
  • AX+ (Assuming X stores result of BC* i.e. B*C)
  • Now finally AX+ can be implemented as A+X

Problem (This is how to convert manually for MCQ Question in the exam)

Problem

  • Infix: a + b * c + d can be written as a + (b * c) + d
  • Now, for all + – / * associativity is left to right we will write it as
  • (a + (b * c)) + d and thus further ((a + (b * c)) + d)
  • Solving and converting innermost bracket to postfix
  • Step 1 –((a + bc*)+ d)
  • Step 2 – Consider bc* as separate operand x the innermost bracket now looks like ((a + x)+ d)
    • Applying postfix it looks like – (ax+ + d)replacing x here (abc*+ + d)
  • Step 3 – Consideringabc*+as separate operand z, the final bracket looks like – (z + d)the result would be zd+
    • replacing z value = abc*+d+

Algorithm (For Code/Manual Calculation)

  1. First Start scanning the expression from left to right
  2. If the scanned character is an operand, output it, i.e. print it
  3. Else
    • If the precedence of the scanned operator is higher than the precedence of the operator in the stack(or stack is empty or has'(‘), then push operator in the stack
    • Else, Pop all the operators, that have greater or equal precedence than the scanned operator. Once you pop them push this scanned operator. (If we see a parenthesis while popping then stop and push scanned operator in the stack)
  4. If the scanned character is an ‘(‘, push it to the stack.
  5. If the scanned character is an ‘)’, pop the stack and output it until a ‘(‘ is encountered, and discard both the parenthesis.
  6. Now, we should repeat the steps 2 – 6 until the whole infix i.e. whole characters are scanned.
  7. Print output
  8. Do the pop and output (print) until stack is not empty
Infix Postfix Prefix Conversion in C using Stacks

Infix to Prefix

Problem (This is how to convert manually for MCQ Question in the exam)

  • Infix: (a / b + c) - ( d + e * f) can be written as ((a / b) + c) - ( d + (e * f))
  • Now, we have done the above according to associativity
  • Solving and converting innermost bracket to prefix
  • Step 1 –(/ab + c) - ( d + *ef)
  • Step 2 – Consider /ab and *ef as separate operand x and y
  • the innermost bracket now looks like (x + c) - (d + y)
    • Applying prefix it looks like – (+xc - +dy)replacing x and y here (+/abc - +d*ef)
  • Step 3 – Considering+/abc and+d*efas separate operand z and w, the final bracket looks like – (z - w)the result would be -zw
    • replacing z and w value = -+/abc+d*ef

Algorithm (For Code/Manual Calculation)

Given Infix - ((a/b)+c)-(d+(e*f))
  • Step 1: Reverse the infix string. Note that while reversing the string you must interchange left and right parentheses.
  • Step 2: Obtain the postfix expression of the expression obtained from Step 1.
  • Step 3: Reverse the postfix expression to get the prefix expression

This is how you convert manually for theory question in the exam

    1. String after reversal – ))f*e(+d(-)c+)b/a((
    2. String after interchanging right and left parenthesis – ((f*e)+d)-(c+(b/a))
    3. Apply postfix – Below is postfix (On this page you check infix to postfix conversion rule)
    4. Reverse Postfix Expression (Given After the image below)
Sr. no.ExpressionStackPrefix
0((
1(((
2f((f
3*((*f
4e((*fe
5)(fe*
6+(+fe*
7d(+fe*d
8) fe*d+
9fe*d+
10(-(fe*d+
11c-(fe*d+c
12+-(+fe*d+c
13(-(+(fe*d+c
14b-(+(fe*d+cb
15/-(+(/fe*d+cb
16a-(+(/fe*d+cba
17)-(+fe*d+cba/
18)fe*d+cba/+
19  fe*d+cba/+-
Final prefix: -+/abc+d*ef
